| Model No. + Lamp Code | CCT | Finish | Option Code |
| LW111-L18 | 27K | PT Powder Coated* | EML Emergency 10W LED Battery |
| 30K | BA Brushed Aluminum | Driver (Remote) | |
| 35K | PC Polished Chrome | BAC Buy America; Buy American Act; | |
| 40K | NT Nickel Touch | and Build America, Buy America Act | |
| GT Gold Touch | Compliant. | ||
| ZT Bronze Touch | |||
| CT Copper Touch | |||
| TT Toffee Touch | |||
| PWT Pewter Touch | |||
| BST Blackened Steel Touch | |||
| CC Custom Painted Finish | *(Specify Color Code from the list of Powder Coating Finishes) |
DIMENSIONS
| BASE MODEL NO. | H | W | D |
| LW111-L18 | 18″ | 10″ | 4″ |
SPECIFICATIONS
Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.
FEATURES
• Opal Matte Acrylic
• Solid Aluminum Material
• LED 0-10V Dimming Driver
LIGHT OUTPUT
LXX = ~ 65 LPW Delivered Lumens (Example: L18= 18W x 65LPW = 1,170 Lumens)
