Model No. + Lamp Code CCT Finish Option Code
LW104-L16  27K PT Powder Coated Finishes* EML Emergency 10W LED Battery
30K XT Trending Brushed Metal Finishes* Driver (Remote)
35K PF Pure Metal Finishes* BAC Buy America; Buy American Act;
40K CC Custom Painted Finish and Build America, Buy America Act
Compliant.
*(Specify Color Code from the list of Finishes – ie. Gold Touch would be ‘GT’)

DIMENSIONS
BASE MODEL NO. H W D
LW104-L16 34″ 4 3/4″ 4″
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Opal Matte Acrylic Diffuser
• LED 0-10V Dimming Driver

LIGHT OUTPUT

LXX = ~ 33 LPW Delivered Lumens (Example: L16= 16W x 33LPW = 528 Lumens)
