| Model No. + Lamp Code | CCT | Finish | Option Code |
| LW103-L34 | 27K | PT Powder Coated Finishes* | EML Emergency 10W LED Battery |
| 30K | XT Trending Brushed Metal Finishes* | Driver (Remote) | |
| 35K | PF Pure Metal Finishes* | BAC Buy America; Buy American Act; | |
| 40K | CC Custom Painted Finish | and Build America, Buy America Act | |
| Compliant. | |||
| *(Specify Color Code from the list of Finishes – ie. Gold Touch would be ‘GT’) | |||
DIMENSIONS
| BASE MODEL NO. | H | W | D |
| LW103-L34 | 34″ | 6″ | 4″ |
SPECIFICATIONS
Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.
FEATURES
• Opal Matte Acrylic Diffuser
• Solid Aluminum Material
• LED 0-10V Dimming Driver
LIGHT OUTPUT
LXX = ~ 83 LPW Delivered Lumens (Example: L34= 34W x 83LPW = 2,822 Lumens)
