| Model No. + Lamp Code | CCT | Finish | OA | Option Code |
| LH112-20-L36 | 27K | PT Powder Coated* | ‘OA’ + Overall Height in Inches (ie. OA96) | EML Emergency 10W LED Battery |
| LH112-30-L54 | 30K | BA Brushed Aluminum | Driver (Remote) | |
| 35K | PC Polished Chrome | BAC Buy America; Buy American Act; | ||
| 40K | NT Nickel Touch | and Build America, Buy America Act | ||
| GT Gold Touch | Compliant. | |||
| ZT Bronze Touch | ||||
| CT Coper Touch | ||||
| TT Toffee Touch | ||||
| PWT Pewter Touch | ||||
| BST Blackened Steel Touch | ||||
| CC Custom Painted Finish | *(Specify Color Code from the list of Powder Coating Finishes) |
DIMENSIONS
| BASE MODEL NO. | H | W | D |
| LH112-20-L36 | 20″ | 12″ | 12″ |
| LH112-30-L54 | 30″ | 12″ | 12″ |
SPECIFICATIONS
Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.
FEATURES
• Opal Matte Glass
• Open Aluminum Frame
• Adjustable Aircraft Cables
• Clear Silver Braided Cord
• LED 0-10V Dimming Driver
LIGHT OUTPUT
LXX = ~ 88 LPW Delivered Lumens (Example: L54= 54W x 88LPW = 4,752 Lumens)
