| Model No. + Lamp Code | CCT | Finish | OA | Option Code |
| LH105-L64 | 27K | PT Powder Coated* | ‘OA’ + Overall Height in Inches (ie. OA96) | EML Emergency Battery Pack with |
| 30K | BA Brushed Aluminum | LED Lighting (Remote) | ||
| 35K | PC Polished Chrome | BAC Buy America; Buy American Act; | ||
| 40K | NT Nickel Touch | and Build America, Buy America Act | ||
| GT Gold Touch | Compliant. | |||
| ZT Bronze Touch | ||||
| CT Copper Touch | ||||
| TT Toffee Touch | ||||
| PWT Pewter Touch | ||||
| BST Blackened Steel Touch | ||||
| CC Custom Painted Finish | *(Specify Color Code from the list of Powder Coating Finishes) |
DIMENSIONS
| BASE MODEL NO. | OAH | W | D |
| LH105-L64 | 48″ | 36″ | 14″ |
SPECIFICATIONS
Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.
FEATURES
• Opal Matte Acrylic Concave Closed Bottom Diffuser
• LED 0-10V Dimming Driver
LIGHT OUTPUT
L64 = ~ 83 LPW Delivered Lumens (Example: L64= 64W x 83LPW = 5,312 Lumens)
