| Model No. + Lamp Code | CCT | Finish | OA | Option Code |
| LH101-L32 | 27K | PT Powder Coated* | ‘OA’ + Overall Height in Inches (ie. OA96) | EML Emergency Battery Pack with |
| 30K | BA Brushed Aluminum | LED Lighting (Remote) | ||
| 35K | PC Polished Chrome | |||
| 40K | NT Nickel Touch | |||
| GT Gold Touch | ||||
| ZT Bronze Touch | ||||
| CT Copper Touch | ||||
| TT Toffee Touch | ||||
| PWT Pewter Touch | ||||
| BST Blackened Steel Touch | ||||
| CC Custom Painted Finish | *(Specify Color Code from the list of Powder Coating Finishes) |
DIMENSIONS
| BASE MODEL NO. | OAH | H | DIA |
| LH101-L32 | 60″ | 16″ | 16 3/4″ |
SPECIFICATIONS
Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.
FEATURES
• Opal Matte Glass
• Internal Driver
• Clear Silver Braided Cord with (3) Adjustable Aircraft Cables
• LED 0-10V Dimming Driver
LIGHT OUTPUT
L32 = ~ 100 LPW Delivered Lumens (Example: L32= 32W x 100LPW = 3,200 Lumens)
