Print This PageDIMENSIONS
| W | H | D | MC | BASE MODEL NO. |
| 6″ | 21″ | 4″ | 10.5″ | S9410-L12 |
| 6″ | 21″ | 4″ | 10.5″ | S9410-L16 |
| 6″ | 27″ | 4″ | 13.5″ | S9411-L16 |
| 6″ | 27″ | 4″ | 13.5″ | S9411-L20 |
SPECIFICATIONS
Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided. Silicone Seal Required (by others).
FEATURES
• Opal Matte Acrylic Lens
• Solid Aluminum Material
• UL Listed for Wet Location
• LED 0-10V Dimming Driver
ORDER AS A COMPLETE UNIT:
Model No. + Lamp Code + CCT + Finish + Option Code
FINISHES
PT Powder Coated Finishes*
SD Shimmer Dimensional Metallic Finishes*
XT Trending Brushed Metal Finishes*
CC Custom Painted Finish
*(Specify Color Code from the list of Finishes [except interior only metallics] – ie. Gold Touch would be ‘GT’)
OPTIONS
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup
LIGHT OUTPUT
LXX = ~ 85 LPW Delivered Lumens (Example: L16= 16W x 85LPW = 1,360 Lumens)
