DIMENSIONS

W H D MC BASE MODEL NO.
8 1/8″ 31″ 4″ 15 1/2″ S9350-L16
8 1/8″ 43″ 4″ 21 1/2″ S9351-L24
8 1/8″ 55″ 4″ 27 1/2″ S9352-L32
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided. Silicone Seal Required  (by others).

FEATURES

• Opal Acrylic
• Solid Aluminum Material
• Solid Aluminum End Caps
• Solid Aluminum Accent Bars
• UL Listed for Wet Location
• LED 0-10V Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish + Option Code

S9350-L16 + 27K + PT + Option
S9351-L24 30K SD
S9352-L32 35K XT
40K
FINISHES

PT Powder Coated Finishes*
SD Shimmer Dimensional Metallic Finishes*
XT Trending Brushed Metal Finishes*

*(Specify Color Code from the list of Finishes [except interior only metallics] – ie. Gold Touch would be ‘GT’)
OPTIONS

BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup

LIGHT OUTPUT

LXX = ~ 75 LPW Delivered Lumens (Example: L16= 16W x 75LPW = 1,200 Lumens)
