Print This PageDIMENSIONS
| W | H | D | MC | BASE MODEL NO. |
| 7 1/4″ | 20 3/4″ | 4″ | 10 3/8″ | S9320-L24 |
| 7 1/4″ | 26 3/4″ | 4″ | 13 3/8″ | S9321-L32 |
SPECIFICATIONS
Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided. Silicone Seal Required (by others).
FEATURES
• Opal Acrylic Lens
• Solid Aluminum Bar Stock Material
• Solid Aluminum End-Caps
• UL Listed for Wet Location
• LED 0-10V Dimming Driver
ORDER AS A COMPLETE UNIT:
Model No. + Lamp Code + CCT + Finish + Option Code
FINISHES
PT Powder Coated Finishes*
SD Shimmer Dimensional Metallic Finishes*
XT Trending Brushed Metal Finishes*
*(Specify Color Code from the list of Finishes [except interior only metallics] – ie. Gold Touch would be ‘GT’)
OPTIONS
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup
LIGHT OUTPUT
LXX = ~ 75 LPW Delivered Lumens (Example: L24= 24W x 75LPW = 1,800 Lumens)
