Print This PageDIMENSIONS
| W | H | BASE MODEL NO. |
| 13 1/8″ | 5 5/8″ | S7185-L12 |
| 17 1/4″ | 6 3/4″ | S7186-L24 |
SPECIFICATIONS
Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.
FEATURES
• Opal Matte Acrylic
• Heavy Gauge Spun Metal Housing Trim
• Solid Metal Bar Trim
• LED 0-10V Dimming Driver
ORDER AS A COMPLETE UNIT:
Model No. + Lamp Code + CCT + Finish + Option Code
| S7185-L12 | + | 27K | + | PT | + | Option |
| S7186-L24 | 30K | BA | ||||
| 35K | BB | |||||
| 40K | BC | |||||
| BN | ||||||
| CC |
FINISHES
| BA Brushed Aluminum BB Brushed Brass BC Brushed Chrom |
BN Brushed Nickel CC Custom Painted Finish PT Powder Coated Finishes* |
| *(Specify Color Code from the list of Powder Coating Finishes) | |
OPTIONS
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup (Requires Additional Power Cable)
FAA Faux Alabaster Acrylic (Hand Painted) [FA1 White; FA2, Antique; FA3 Grey; FA4 Taupe; FA5 Honey, FA6 Tuscan]
LIGHT OUTPUT
LXX = ~ 89 LPW Delivered Lumens (Example: L12= 12W x 89LPW = 1,068 Lumens)
