DIMENSIONS

W H D MC BASE MODEL NO.
36″ 4″ 4″ 18″ S3A05-L18
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Opal Matte Acrylic Bottom and Top Lens
• Can be mounted horizontally or vertically
• Solid Aluminum Material
• LED 0-10V  1% Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish +  Option Code

S3A05-L18 + 27K + PT + Option
30K XT
35K CC
40K
FINISHES

PT Powder Coated Finishes*
XT Trending Brushed Metal Finishes*
CC Custom Painted Finish

*(Specify Color Code from the list of Finishes – ie. Gold Touch would be ‘GT’)
OPTIONS

BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup

LIGHT OUTPUT

LXX = ~ 80 LPW Delivered Lumens (Example: L18 = 18W x 80LPW = 1,440 Lumens)
