DIMENSIONS

W H D MC BASE MODEL NO.
10 1/4″ 14″ 4″ 7″ S3995-L18
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Opal Matte Acrylic
• Solid Metal Bottom Reveal
• ADA Compliant
• LED 0-10V Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish + Option Code

S3995-L18 + 27K + PT + Option
30K BA
35K BB
40K BN
FINISHES
BA Brushed Aluminum
BB Brushed Brass		 BN Brushed Nickel
PT Powder Coated Finishes*
*(Specify Color Code from the list of Powder Coating Finishes)
OPTIONS

BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup

LIGHT OUTPUT

LXX = ~ 81 LPW Delivered Lumens (Example: L18= 18W x 81LPW = 1,458 Lumens)
