DIMENSIONS

W H X A BASE MODEL NO.
6 1/2″ 48″ 3″ 4 3/4″ S2930-L12
18 1/2″ 48″ 9″ 13 1/2″ S2932-L54
SPECIFICATIONS

Driver: 0-10V Dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Opal Matte Acrylic Interior Lens
• Clear Silver Braided Cord with Adjustable Aircraft Cables
• Seamless Aluminum Material
• LED 0-10V Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Exterior Finish + Trim/Canopy Finish + OA +  Option Code

S2930-L12 + 27K + PT ZT + PT ZT + OA + Option
S2932-L54 30K BA TT BA TT
35K NT PWT NT PWT
40K GT BST GT BST
CT CC CT CC
EXTERIOR FINISHES
BA Brushed Aluminum
NT Nickel Touch
GT Gold Touch
ZT Bronze Touch
CT Copper Touch		 PWT Pewter Touch
TT Toffee Touch
BST Blackened Steel Touch
CC Custom Painted Finish
PT Powder Coated Finishes*
*(Specify Color Code from the list of Powder Coating Finishes)
TRIM/CANOPY FINISHES
BA Brushed Aluminum
NT Nickel Touch
GT Gold Touch
ZT Bronze Touch
CT Copper Touch		 PWT Pewter Touch
TT Toffee Touch
BST Blackened Steel Touch
CC Custom Painted Finish
PT Powder Coated Finishes*
*(Specify Color Code from the list of Powder Coating Finishes)
OPTIONS

BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup (Requires Additional Power Cable)
1S Stem Mount
BK1 Black Cord with (1) Adjustable Aircraft Cable
WH1 White Cord with (1) Adjustable Aircraft Cable

LIGHT OUTPUT

LXX = ~ 88 LPW (S2932) Delivered Lumens (Example: L54= 54W x 88LPW = 4,752 Lumens) or ~70 LPW (S2930) Delivered Lumens (Example: L12= 12W x 70LPW = 840 Lumens)
