DOWNLOADS

 Product Cutsheet

DIMENSIONS

W H X BASE MODEL NO.
8″ 36″ 10″ S2840-L15
8″ 36″ 10″ S2840-L15A
SPECIFICATIONS

Driver: (L15) 0-10V dimming to 1%, 120/277V; OR (L15A) no driver – ELV dimming 120V only
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Solid Aluminum Construction
• Open Bottom
• Clear Silver Braided Cord Suspension
• 2-Tone Finish
• LED 0-10V  or ELV Dimming Driver

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish + Finish (Interior) + Option Code

S2840-L15 + 27K + PT + WH + Option
S2840-L15A 30K XT BA
35K
40K
FINISHES

Exterior Finish
PT Powder Coated Finishes*
XT Trending Brushed Metal Finishes*
PF Pure Metal Finishes*
CC Custom Painted Finish

*(Specify Color Code from the list of Finishes – ie. Gold Touch would be ‘GT’)



Interior Finish
BA Brushed Aluminum WH Painted White
OPTIONS

BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup (Requires Additional Power Cable)
OA Specify Overall Height of Fixture in Inches; e.g. – OA96
BKO Black Cord Suspension
WHO White Cord Suspension

LIGHT OUTPUT

LXX = ~ 105 LPW Delivered Lumens (Example: L15= 15W x 105LPW = 1,575 Lumens)
