DIMENSIONS

W H X BASE MODEL NO.
11″ 48″ 24″ S2135-L48
13″ 48″ 30″ S2136-L64
SPECIFICATIONS

Driver: 0-10V dimming to 1%, 120/277
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.

FEATURES

• Opal Matte Acrylic Cylinder
• 16W LED Downlight Standard with Optional Separate Control
• LED 0-10V 1% Dimming Drivers

ORDER AS A COMPLETE UNIT:

Model No. + Lamp Code + CCT + Finish + OA +  Option Code

S2135-L48 + D16N + 27K + PT + OA + Option
S2136-L64 D16M 30K BA
D16W 35K BB
40K BC
PB
PC
DOWNLIGHT LENS

D16N 12 degrees (50% Beam Angle) 24 degrees (10% Beam Angle)
D16M 19 degrees (50% Beam Angle) 31 degrees (10% Beam Angle)
D16W 38 degrees (50% Beam Angle) 55 degrees (10% Beam Angle)
D16 = Downlight – 16 Watts

FINISHES
BA Brushed Aluminum
BB Brushed Brass
BC Brushed Chrom		 PB Polished Brass
PC Polished Chrome
PT Powder Coated Finishes*
*(Specify Color Code from the list of Powder Coating Finishes)
OPTIONS

BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
EML Remote 10W Emergency LED Battery Backup
OA Specify Overall Height of Fixture in Inches; E.G. – OA204
FAA Faux Alabaster Acrylic (Hand Painted) [FA1 White; FA2, Antique; FA3 Grey; FA4 Taupe; FA5 Honey, FA6 Tuscan]
SWC 35-Degree Swivel Canopy (Single Stem Only)
DL Damp Label Mod – Mods include Post-Painted Parts, Conformal Coated LED Boards, Guy Wire Loops
TPC Clear Acrylic Top Cover

LIGHT OUTPUT

LXX = ~ 69 LPW Delivered Lumens (Example: L48= 48W x 69LPW = 3,312 Lumens)
