Print This PageDIMENSIONS
| W | H | X | BASE MODEL NO. |
| 4 1/2″ | 36″ | 12″ | S2128-L10A |
SPECIFICATIONS
Driver: ELV Dimming Only, 120V Only
Mounting: Mounts to all Standard Electrical Junction Boxes (by others) With Hardware Provided.
FEATURES
• Cased Opal Glass – Open Bottom
• Clear Silver Braided Cord with (1) Adjustable Aircraft Cable
• LED DOB Puck
ORDER AS A COMPLETE UNIT:
Model No. + Lamp Code + CCT + Finish + OA + Option Code
| S2128-L10A | + | 27K | + | PT | + | OA | + | Option |
| 30K | BA | |||||||
| 35K | BB | |||||||
| 40K | BC | |||||||
| PB | ||||||||
| PC |
FINISHES
| BA Brushed Aluminum BB Brushed Brass BC Brushed Chrom |
PB Polished Brass PC Polished Chrome PT Powder Coated Finishes* |
| *(Specify Color Code from the list of Powder Coating Finishes) | |
OPTIONS
BAC Buy America; Buy American Act; and Build America, Buy America Act Compliant.
OA Specify Overall Height of Fixture in Inches; e.g. – OA48
CWA Cherry Wood Acrylic
LAC Linen Acrylic
OMA Opal Matt Acrylic
SEN Sienna Hand Blown Cased Glass
1S Single Stem
GU24 GU24 Lamping
1T60 E27 Socket
LIGHT OUTPUT
LXX = ~ 63 LPW Delivered Lumens (Example: L10= 10W x 63LPW = 630 Lumens)
