| Einka Mirror | Height (in.) | Width (in.) | Source | Options |
| SM050 = Glass | 30″ | 24″ | L930K (Standard) | NL = Night Light (Separate Circuit) |
| 36″ | 30″ | Options: | NS = Night Light w/ Touch Switch | |
| 40″ | 36″ | L927K | SD = Step Dimming via Touch Switch | |
| 40″ | L935K | BAC = Buy America; Buy American Act; and | ||
| 48″ | L940K | Build America, Buy America Act Compliant. | ||
| 54″ | For other options, consult factory. |
SPECIFICATIONS
Housing: Post Powder Coated Heavy Ga. Paintlok™ Steel Housing for structural integrity, Aluminum LED bracketry for heat sinking
LED: 3000K, 90CRI, Constant Voltage. ~7W per linear foot of mirror perimeter.
Driver: Constant voltage 0-10V dimming driver, 120/277V. (Consult factory for other options.)
Mirror: 5MM glass w/polished edges. (Optional 3/16″ silvered acrylic w/polished edges.)
Translucent Frost: Opalex coating process resists fingerprints on frosted panels.
Wiring: Hardwired connection for centrally located J-Box (by others).
